    OFM-12-DP 12-Channel Optical Delay Phase Modulator

    Precisely matching optical path lengths and phase, with loading up to 12 independent channels

    OFM-12-DP 12-channel optical delay phase modulator is designed to precisely match optical path lengths and modulate the phase of multiple laser channels. It effectively solves the problem of phase matching and reduced coherence length in high-power, narrow-linewidth lasers caused by spectral broadening. The OFM-12-DP optical delay phase modulator integrates 12 independent channels, each with its own optical delay line and electro-optic phase modulator, allowing for a wide range of delay adjustments and high-precision phase control.

    Request a Quote
    Parameters
    Optical Characteristics
    Laser wavelength (nm) 1064±2
    Insertion loss (dB) ≤6
    Polarization extinction ratio (dB) >18 (fast axis cut-off)
    Max. input power (mW) 300
    Delay accuracy (ps) 0.05
    Delay range (ps) 0-330
    Optical Interfaces
    Input fiber type PM980
    Input fiber interface FC/APC
    Input fiber length (m) 1
    Output fiber type PM980
    Output fiber interface FC/APC
    Output fiber length (m) 1
    Electrical Characteristics
    Phase modulation half-wave voltage Vp (V) ≤2.5 @ 50kHz
    Phase modulation bandwidth (MHz) ≥200
    Return loss (dB) ≤-10
    Impedance (Ω) 50
    Environmental Adaptability
    Operating conditions -40 to +85°C, < 90%RH, can be reinforced for special environments
    Storage conditions -40 to +85°C, < 90%RH, can be reinforced for special environments
    Features
    • Dual-Mode Modulation Technology
      Delay modulation: Supports picosecond (ps) to nanosecond (ns) laser pulse delay adjustments with sub-picosecond resolution, ideal for applications requiring strict timing synchronization (e.g., quantum entanglement experiments).
      Phase modulation: Offers a modulation rate of 100MHz and highly linear phase control, enabling dynamic beam wavefront shaping or light field coherence optimization.
    • Array Integration Design
      Integrates 12 independent modulation channels, supporting synchronous or asynchronous control of multiple lasers to reduce system size and complexity.
      Utilizes a Lithium Niobate (LiNbO₃) material process to ensure low insertion loss (<3 dB) and high stability.
    • Smart Control Interface
      Supports dual-mode operation via electronic control or software programming, compatible with external control modules like FPGAs and DSPs for real-time dynamic adjustments.
      Provides an API for seamless integration into automated optical experimental platforms or industrial equipment.
    Applications
    • Coherent synthesis
      For matching optical path differences and phase control in laser array optical paths.
    • Laser phased arrays
      For dynamic beam shaping and atmospheric turbulence compensation of laser arrays.
    • Lidar
      Enables timing synchronization and beamforming for multi-beam scanning.
    • Fiber sensing
      Enhances distributed acoustic/temperature sensing performance through phase detection technology.
    Advantages
    • High precision
      Features all-temperature-range (-40°C to 85°C) phase drift compensation technology, ensuring long-term stability.
    • Scalability
      Supports cascading of modules to expand to 24 or 48-channel arrays, adapting to the needs of large-scale laser array coherent control.

    With its multi-channel, high-precision, and strong compatibility, the OFM-12-DP optical delay phase modulator is a core component for both cutting-edge optical research and industrial-grade laser systems.
